The ergonomic Euromex BlueLine microscopes’ optical performance facilitates long, productive sessions for science teaching classes for beginner, intermediate, and advanced students. School microscopes must be easy to use and student-friendly, meaning that they should withstand intensive use and rough treatment.

The outstanding optical performance of the ergonomic Euromex BlueLine microscopes enables long productive working sessions for students for beginner, intermediate, and advanced science teaching classes.

The modern microscopes in the EcoBlue series are specially designed for teaching purposes, with a focus on ergonomics and excellent value for money. These microscopes come with secured eyepieces, achromatic objectives and an adjustable rack stop to prevent damage to samples and objectives.

EYEPIECES • Wide field WF 10x /18mm eyepiece with pointer • Eyepieces for binocular and trinocular models are supplied without a pointer

TUBE • Monocular models have 45° inclined eyepiece • Binocular and trinocular models have 30° inclined tubes • The interpupillary distance is adjustable between 48 and 75mm • All binocular and trinocular models have a dioptre adjustment of ± 5 dioptres on the left tube • All heads are 360° rotatable • Models with an integrated USB 2.0 camera are supplied with a 5.0 MP 1/2” CMOS sensor with a resolution of 2560x1920 pixels • The EcoBlue can also be supplied with a discussion head

NOSEPIECE • Revolving 4-objective nosepiece on ball bearings • Models for polarisation are supplied with a swing-out analyser

45 MM PARFOCAL OBJECTIVES • Achromatic 4x/0.10, 10x/0.25, S40x/0.65 and S100x/1.25 objectives • The S40x, S60x, and S100x oil immersion objectives are spring loaded • The HLED-S models for polarisation are equipped with semi-plan objectives • All objectives are anti-fungus treated and AR-coated to ensure maximum light throughput

FOCUS ADJUSTMENT • Coaxial coarse and fine focus adjustment, 200 graduations, 12.5 µm per graduation, 2.5mm per rotation, total travel approx. 15mm • Supplied with an adjustable rack stop to prevent damage to the sample and objectives

STAGE • 123x119mm with two non-removable object clamps (optional 51x26 mm X-Y mechanical stage available for the EC.9500) • Stage 123x128mm with integrated 70x27mm X-Y mechanical stage • The models for polarisation are supplied with a 129mm round stage, 360° rotatable, and 2 object clamps

CONDENSER • Height-adjustable Abbe condenser N.A. 1.25 with iris diaphragm and filter holder • Models for polarisation have a rack and pinion adjustment, all other models have a spiral adjustment

ILLUMINATION combined NeoLED • Monocular models are supplied with an adjustable 1W LED illumination with integrated power supply • Binocular and trinocular models are supplied with an adjustable 1W NeoLED™ illumination system for increased light output • EC.1151, EC.1152, EC.1153, EC.1652 and EC.1653 are supplied with rechargeable batteries and an external 100-240V battery charger/mains adapter • The polarisation models are equipped with H-LED illumination for correct colour rendering (very similar to the halogen light spectrum) with integrated 100-240V power supply, no batteries

ANTI-THEFT SLOT • A Kensington security slot is located on the back of the microscope to allow the instrument to be protected from theft

PACKAGE CONTENTS • Includes power cable or AC adapter/charger, white filter, dust cover, spare fuse, user manual and 5 ml immersion oil for models with an S100x objective • The EcoBlue models with external AC adapter and X-Y stage (EC.1x5x) are supplied with three rechargeable AA batteries • All packed in a polystyrene box

DIGITAL MODELS CAMERA • All EcoBlue digital microscopes are equipped with a 5.0 MP CMOS USB 2.0 camera • Maximum resolution 2560x1920, 24-bit colour depth, up to 30 frames per second • ImageFocus Plus software included, USB 2.0 cable and micrometre 1mm/100 slides Camera supplied with a 2-year warranty

SOFTWARE • Supplied with ImageFocus Plus for capturing images and videos • ImageFocus Plus capture and analysis software can store images in JPG, TIF, BMP, and videos in AVI format. • This software also enables comprehensive analysis, such as measurements on still and live images and annotations on captured images • Images can be annotated and measurements taken on live or captured images • Compatible with Windows 7, 8, 10 and 11, 32- and 64-bit configurations • A Mac OS Light version is also available for image capture • Updates can be downloaded from our website under www.euromex.com

The modern microscopes of the EcoBlue series are especially developed for educational purposes with primary focus on ergonomic and excellent price/quality ratio. These microscopes are supplied with secured eyepieces, achromatic objectives and an adjustable rack stop to prevent damage to sample and objectives.

• Monocular, binocular and trinocular upright models
• WF10x/18 mm eyepiece(s)
• Models with integrated 3.2 MP CMOs camera
• Models for polarization applications
• Revolving nosepiece with 4 achromatic objectives
• Models with integrated mechanical stage available
• Coaxial coarse and fine adjustments with rack stop
• Height adjustable abbe condenser with iris diaphragm and filter holder
