The ergonomic Euromex BlueLine stereo microscopes’ optical performance facilitates long, productive sessions for science teaching classes for beginner, intermediate and advanced students.

EduBlue stereo microscopes have been specially designed for educational establishments and are equipped with dual or triple objectives, which allow magnification from 5x up to a maximum of 80x. All models are equipped with adjustable LED incident and transmitted illumination. The two parallel optical tubes allow three-dimensional observation of small insects, plants, stones and minerals.

High quality, yet affordably priced Euromex microscopes specifically match these demands due to the well-thought construction and usage of top-class material.

EYEPIECES • Two secured WF10x/20mm eyepieces with eyecups

HEAD • Binocular 45° inclined tubes • Trinocular head with 45° inclined tubes and 23.2mm trinocular tube. The 23.2mm tube is compatible with all standard 23.2mm C-mount objectives • Dioptre adjustment ± on the left eyepiece • Inter pupillary distance adjustable between 55 and 75mm • Digital version is equipped with 5.0 MP USB 2.0 1/2.8” CMOS camera • Resolution 2560x1920 pixels

DUAL MAGNIFICATION OBJECTIVES • Revolving nosepiece with dual magnification 1x/3x, 2x/4x • Working distance 60mm • Field of view 20/6.7mm or 10/5mm • Magnification can be altered with optional eyepieces • All optics are anti-fungus treated

TRIPLE MAGNIFICATION OBJECTIVES • Revolving nosepiece with triple magnification 1x/2x/3x, 1x/2x/4x • Working distance 60mm • Field of view 20/10/5/6.7 mm or 20/10 mm • Magnification can be altered with optional eyepieces

STAND • Rack and pinion or column stand equipped with 2 object clamps and Ø 60 mm transparent and black/white plate • Two coarse adjustment knobs are white hardened coating • The stands are alloy metal cast with hardened coating • The EduBlue rack and pinion stands are equipped with graduations and focus point indicator for fast focusing • EVO models are equipped with a built-in movable object stage

ILLUMINATION • Transmitted and incident 1W LED illumination that can be used simultaneously • Adjustable illumination intensity • Built-in 1,800 mAh rechargeable battery with AC/DC adapter • Evo models are equipped with an additional flexible arm with 1W LED illumination

PACKAGE CONTENTS • Supplied with an external 100-240 V mains adapter/charger and three rechargeable batteries for wired and wireless operation, dust cover, Ø 60 mm transparent and black/white stage plates, eyecups and operating instructions. • Everything is packed in a polystyrene box

DIGITAL CAMERA (digital models) • Digital models are equipped with 5.0 MP camera, USB 2.0 • resolution 2560x1920 pixels, 24-bit colour depth, up to 30 frames per second. Smaller resolutions are selectable • Supplied with ImageFocus Plus software as standard, USB 2.0 cable and micrometre 1mm/100 slides • 2 year warranty

SOFTWARE • Supplied with ImageFocus Plus for capturing images and videos • This software allows for a wide range of analyses, such as measurements on still and live images and annotations on already captured images  • Save images in .jpg, .tif, .bmp formats and videos in AVI format • Compatible with Windows 7, 8 and 10, all 32- and 64-bit configurations • Mac OS software is available as a light version • Updates can be downloaded from our website

The modern MicroBlue is an entry-level microscope and is especially appreciated when budget is limited. The basic model comes with a fixed lens condenser and a plain stage.All models with an integrated mechanical stage are supplied with an Abbe condenser. All models are equipped with 35 mm achromatic objectives. The built-in rechargeable batteries enable cordless operation.

• Entry-level upright microscopes
• Monocular and binocular models
• Revolving reversed nosepiece
• Integrated X-Y mechanical stage
• LED and NeoLED illumination
• Cordless operation
• Ergonomic carrying grip
